FINGER CNC

G Series Edge Computing Digital Gateway


G4-G00M06C240

Follow frequency:

Product type:Edge Computing Digital Gateway

More





Basic Parameters

Chip Architecture

ARM A55 Quad-core Architecture

CPU Frequency

Single Core Performance: 2.0GHz

RAM

4GB LPDDR4

Storage

64GB EMMC5.0

Communication Interface

Serial Port

6 serial communication ports, including 2 RS232 interfaces and 4 RS485 interfaces.

Ethernet Interface

2 x 100Mbps Adaptive Ethernet Ports

Industrial-Grade Protection

EMC

4.5KV (Power, Coupling)

Vibration (Operating/Storage)

7mm@2~9Hz;2g@10~500Hz

Operating Temperature

-20~85℃

Storage Temperature

-20~85℃

Power Consumption

Supply Voltage

24 VDC

Power Consumption

10W

Cooling Method

Passive Cooling

Installation Dimensions

Installation Method

Free Installation

Dimensions

158*108*30 mm

Weight (kg)

0.6

Material Appearance

Dark Gray

Software System

Software Platform

Finger GateWay Link IDE

Data Acquisition Interface Library

6 types extendable

Data Processing Capability

20,000 points

Operating System

Debian 11

Data Forwarding Interface Library

3 types extendable
