B Series 15-inch Motion Touch Screen All-in-One Controller
B01-TX5A1N
Follow frequency:次
Product type:Touch Integrated Machine
Follow frequency:次
Product type:Touch Integrated Machine
Name | Motion Controller | |
Specification Description | Maximum Axis Count | 40 Groups (Pulse/Analog/MECHATROLINK-II/EtherCAT Bus/PWM) |
Maximum Spindle Count | 10 Groups (Analog Open Loop/Closed Loop/Pulse Command/MECHATROLINK-III/EtherCAT Bus) | |
Minimum Calculation Cycle | 0.5ms | |
Bus Functionality | Supports MECHATROLINK-III/EtherCAT Bus Protocols | |
Control Method | Position Control, Speed Control (Adjustable Bandwidth), Torque Control | |
Screen Size | HDMI | |
Electronic Cam, PID Control | Supported (Unlimited Cam Curve, 16 Sets of PID Feedforward/FB per Channel) | |
Maximum Input/Output | 256/256 (1ms 64IN/OUT,4ms 192 IN/OUT) | |
MES Module | Supported (Supports only 16Bit MODBUS Standard Protocol, Custom Protocols, Communication Library Mode) | |
Communication Protocols (Master, Slave) | MODBUS、TCP/IP、FTP | |
Communication Protocol Interfaces | USB 3.0*2/USB 2.0*2 | |
Acceleration/Deceleration Type | Linear, S-Curve, Jerk | |
AD/DA | Expansion Module (Expandable up to 32 Groups) 14BIT | |
Fast Input Signal for Fixed-Length Motion | Supported (High-Precision Response Cycle of 0.5us Error) | |
PWM Output | 5000kbps | |
Serial Absolute Encoder | SI (6 Groups, Expandable up to 12 Groups) | |
DXF Vector Graphics Import | Supported | |
Network Server | Supported (Including Multi-Slave Functionality) | |
WIFI Communication | Supported (Optional) | |
Storage Capacity | 8GB | |
Memory | 2GB | |
Touch Functionality | Optional | |
Mouse, Keyboard | Supported |
